SS316L Wafer Butterfly Valve
- Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
- Including shipping costs, sent by valvesonly.com
- Pick up at a valvesonly.com collection point is possible
- 30 days to change your mind and free returns
- Day and night customer service
Description
SS316L Wafer Butterfly Valve
Body: SS316L, Carbon Steel, Cast Iron, Ductile Iron
Disc: Aluminium Bronze, Carbon Steel, Cast Iron, Ductile Iron, SS304, SS316
Stem: SS410, SS420, SS416, SS304, SS316, Monel
Seat Lining: EPDM, NBR, Viton, PTFE
Packing: Graphite, PTFE
Handle: Aluminium, Cast Iron
Nominal Diameter: DN50 to DN2000
Nominal Pressure: PN10 to PN40, Class150
End Connections: Wafer
Operation: Lever Operated, Gear Operated, Electric Actuated, Pneumatic Actuated
Design and Manufacture: API609
Face to Face Dimension: API609, MSS SP-67, MSS SP-68, BS EN1092
End Connection Standard: ASME B16.5, DIN2501
Inspection and Test: API598
Dimensions Unit: mm
PN10
| DN | B | A | C | L | фK | F | N-фd |
| 40 | 67 | 141 | 32 | 33 | 110 | 50 | 4-ø18 |
| 50 | 67 | 141 | 32 | 43 | 125 | 50 | 4-ø18 |
| 65 | 75 | 151 | 32 | 46 | 145 | 50 | 4-ø18 |
| 80 | 95 | 160 | 32 | 46 | 160 | 70 | 8-ø18 |
| 100 | 111 | 180 | 32 | 52 | 180 | 70 | 8-ø18 |
| 125 | 129 | 193 | 32 | 56 | 210 | 70 | 8-ø18 |
| 150 | 142 | 207 | 32 | 56 | 240 | 102 | 8-ø22 |
| 200 | 170 | 240 | 45 | 60 | 295 | 102 | 8-ø22 |
| 250 | 206 | 270 | 45 | 68 | 350 | 102 | 12-ø22 |
| 300 | 238 | 316 | 45 | 78 | 400 | 125 | 12-ø22 |
| 350 | 267 | 368 | 45 | 78 | 460 | 125 | 16-ø22 |
| 400 | 298 | 400 | 51 | 86 | 515 | 140 | 12-ø26 |
| 450 | 318 | 422 | 51 | 105 | 565 | 140 | 20-ø26 |
| 500 | 349 | 479 | 57 | 130 | 620 | 165 | 20-ø26 |
| 600 | 410 | 562 | 70 | 152 | 725 | 254 | 20-ø30 |
Additional information
| Body Material | SS316L |
|---|---|
| Class | 150/PN16 |
| Disc | SS316L |
| Size | 3", 4", 6" |
