2 Piece Forged Steel Ball Valve
1. Body: A105, F304, F316, F304L, F316L
2. Ball: F304, F316, F304L, F316L
3. Seat: PTFE, RPTFE
4. Gasket: PTFE
5. Bonnet: A105, F304, F316, F304L, F316L
6. Packing: PTFE
7. Packing Gland: SS304
8. Nut: A194B7, A1948
10. Stem: SS316, SS304
11. Thrust Washer: RPTFE
12. Handle: PVC
Nominal Size: 1/4" to 3"
Nominal Pressure: Class800 to Class2500
Design Standard: ASME B16.34
Face to Face: DIN3202
Test and Inspection: API598
Working Temperature: -20℃~150℃
Dimensions Unit: mm
| Size | L | фd | H | W |
| ¼” | 70 | 6 | 51 | 108 |
| 3/8” | 70 | 9 | 51 | 108 |
| ½” | 70 | 13 | 51 | 108 |
| ¾” | 80 | 17 | 68 | 146 |
| 1” | 95 | 23 | 68 | 178 |
| 1 ¼” | 115 | 28 | 85 | 178 |
| 1 ½” | 125 | 35 | 105 | 230 |
| 2” | 135 | 49 | 105 | 230 |
| 2 ½” | 155 | 63 | 125 | 280 |
| 3” | 180 | 80 | 180 | 280 |
