Forged Cryogenic Trunnion Ball Valve
In Stock
- Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
- Including shipping costs, sent by valvesonly.com
- Pick up at a valvesonly.com collection point is possible
- 30 days to change your mind and free returns
- Day and night customer service
Description
Forged Cryogenic Trunnion Ball Valve
Body: Stainless Steel, Cryogenic Alloy Steel, Duplex Stainless steel
Floating and Trunnion mounted ball valve(Side and Top Entry)
Nominal Diameter: DN15 to DN65
Nominal Pressure: Class 150 to Class 1500
End connection: RF, RTJ, BW
Working temperature: -196ºC to +200ºC
Medium: Water, Gas , Oil, Nitric acid, Acetic acid
Temperature: -28ºC~300ºC
Actuator Type: GT Or AW Series
Air pressure: 0.3 to 0.7MPa
Dimension
Inch |
Size(mm) |
||||||
DN | D0 | D1 | L | B | H | E | |
1/2″ | 15 | 15 | 19 | 82 | 10 | 193 | 180 |
1″ | 25 | 25 | 33 | 82 | 12 | 218 | 200 |
1 1/2″ | 40 | 40 | 46 | 113 | 15 | 246 | 200 |
2″ | 50 | 50 | 58 | 157 | 15 | 336 | 360 |
2 1/2″ | 65 | 65 | 77 | 177 | 15 | 450 | 360 |
