Description

F44 Gate Valve

Body: F44, Super Duplex Stainless Steel, Alloy 20, CN7M, Hastelloy, Carbon Steel, WC6, WC9,

C5, C12, LCB, CF3M

Bonnet, Gate: F44, Super Duplex Stainless Steel, Alloy 20, CN7M, Hastelloy, Carbon Steel, WC6,

WC9,  C5, C12, LCB, CF3M

Trim: SS304, SS316, SS304L, SS316L, 13%Cr.Steel, Stellite, Hastelloy, Alloy 20, Duplex Stainless Steel, Super

Duplex Stainless Steel

Gland Packing: Graphite, PTFE

Nominal Size: 2″ to 48″

Nominal Pressure: Class150 to Class600

End Connections: Flanged, Socketweld, Buttweld

Operations: Handwheel Operated, Electric Actuated, Pneumatic Actuated

Design and Manufacture: ANSI B16.34, API 600, API 6D, API 603, BS1414

Face to Face Dimensions: ANSI B16.10, API 6D

Flanged End Dimension: 2″ to 24″ , ANSI B16.5, 26″ to 36″,  MSS-SP-44 to API605

Inspection and Test: API 598, API 6D

Dimensions

SIZEL(RF/BW)L(RTJ)HWWEIGHT(RF)WEIGHT(BW)
INmmmmmmmmkgkg
2”2162324002003026
2 ½”2412574772503934
3”2832985432505547
4”3053216503008368
5”3813977703009277
6”403419880350137118
8”4194351037450240195
10”4574731275500333271
12”5025181438560536432
14”7627781650460699595
16”83885418404601010848
18”914930203061012051025
20”9911010224061017201460
24”11431165290061028002294
28”13461371310061031502870
30”13971422354061037863220
32”15241522386061042103675
36”17271756431261068504990
40”1930–479176084606160
42”1981–503276095006800
48”2235–5522760124009000
