F347 Dual Plate Wafer Check Valve

Body: F347, Alloy 20, Monel, Duplex, Super Duplex, Inconel, Hastelloy C276/B3, Titanium, Carbon Steel

Disc: F347, Alloy20, ss304, ss316

Seal: PTFE, RPTFE, PPL

Seat: 13Cr, Stellite

Nominal Size: 2″ to 24″

Nominal pressure: PN1.6, PN2.5Mpa, PN4.2MPa, Class150 to Class300

End Connection: Wafer

Design and Manufacture: ANSI B16.34, API 6D, DIN 3840, BS EN 1868

Face to Face Dimensions: ANSI B16.10, API 6D, DIN3202, BS EN558-1

Flange End Dimensions: ANSI B16.5, DIN 2543, BS EN 1092-1

Buttweld End Dimensions: ANSI B16.25

Test and Inspection: API598, API6D, DIN3230, BS EN 12569

Dimensions

DNDD1D2LRT
2″1026532542925
2.5″1217842.1603629.3
3″13494826743.427.7
4″17111797.56755.626.7
5″193145111.88367.638.6
6″2191711279578.646.3
8″276222161.7127104.466
10″336276213.414012870.7
12″406327237.9181156.7102
14″448375312.2184179.889.2
16″511416351191198.492.5
18″546467409203226.296.2
20″603514451.9213248.2102.7
24″714616554.7222297.4107.3
