F347 Trunnion Mounted Ball Valve

Body: F347, Titanium, CF8, CF8M, Cast Iron, Carbon Steel

Ball: F347, Titanium, CF8, CF8M, Cast Iron, Carbon Steel

Stem: SS304, SS316

Gland Nut: SS304, SS316

Seat: PTFE, RTFE, PPL

Seal: PTFE

Packing: PTFE, Graphite

Nominal Size: 2″ to 24″

Nominal Pressure: Class 150 to Class 2500, PN16 to PN63

End Connection: Flanged

Handle: Lever Handle, Locking Device Handle

Operation: Manual, Pneumatic, Electric Actuated

Design and Manufacture Standard: ASME B16.34, API 6D

Face to Face Dimension: DIN3202, EN1266, ANSI B16.10

Flanged End Dimension: ANSI B16.5

Buttweld Dimension: ANSI B16.25

Inspection and Testing: API 598

Dimensions

NPS in 2 2 1/2 3 4 6 8 10 12 14 16 18 20 24
d mm 51 64 76 102 152 203 254 305 337 387 432 483 584
L(RF) mm 216 241 283 305 403 502 568 648 762 838 914 991 1143
d1 mm 92 105 127 157 216 270 324 381 413 470 533 584 692
d2 mm 127 149 168.5 200 270 330 387.5 451 514.5 571.5 628.5 686 813
D mm 165 190 210 254 318 381 445 521 584 648 711 775 914
b mm 23 26 29 32 37 42 48 51 54 58 61 64 70
n-Фd mm 8-19 8-22 8-22 8-22 12-22 12-25 16-29 16-32 20-32 20-35 24-35 24-35 24-41
H mm 176 200 215 252 330 448 505 556 620 700 750 805 1110
W mm 350 400 400 500 1000 300 350 400 500 500 500 500 500
