Non Slam Swing Check Valve
$232.00 – $477.00
In Stock
- Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
- Including shipping costs, sent by valvesonly.com
- Pick up at a valvesonly.com collection point is possible
- 30 days to change your mind and free returns
- Day and night customer service
Description
Non Slam Swing Check Valve
Body: Cast Iron, Ductile Iron
Disc: Ductile iron, Aluminium Bronze, Stainless Steel
Spring: Stainless Steel
Shaft: Stainless Steel
Seat Ring: EPDM, NBR
Nominal Diameter: DN40 to DN600
Nominal pressure: Class150 to Class2500
Design and Manufacture: API6D
Face to Face Dimension: ASME B16.10
Flanged End Dimension: ANSI B16.5, ANSI B16.47
Buttweld Dimension: ANSI B16.25
Inspection and Test: API598
Dimensions Unit: mm
PN10
DN | L | D | K | b | Z-фd |
40 | 112 | 145 | 110 | 18 | 4-ф18 |
50 | 120 | 160 | 125 | 20 | 4-ф18 |
65 | 130 | 180 | 145 | 20 | 4-ф18 |
80 | 150 | 195 | 150 | 22 | 8-ф18 |
100 | 165 | 215 | 180 | 24 | 8-ф18 |
125 | 190 | 245 | 210 | 26 | 8-ф18 |
150 | 210 | 280 | 240 | 26 | 8-ф22 |
200 | 255 | 335 | 295 | 28 | 8-ф22 |
250 | 310 | 390 | 350 | 28 | 12-ф22 |
300 | 320 | 440 | 400 | 28 | 12-ф22 |
350 | 380 | 500 | 460 | 30 | 16-ф22 |
400 | 405 | 565 | 515 | 32 | 16-ф26 |
450 | 430 | 615 | 565 | 32 | 20-ф26 |
500 | 450 | 670 | 620 | 34 | 20-ф26 |
600 | 510 | 780 | 725 | 36 | 20-ф30 |
Additional information
Body Material | Wcb |
---|---|
Class | 150/PN16 |
Size | 10", 6", 8" |
